400W 12V Solar Premium Kit for RVs & Campers

Generates an average of 1600 wh of electricity per day
Grade A solar cell, 22.8% efficient charging and energy storage device.
30A MPPT charge controller, tracking efficiency up to 99%.
Easy to install: solar panels have pre-drilled holes, accessories are plug and play.

Specification
100W Monocrystalline Solar Panel
Max Power: 100W
Cell Type: MONO210 Solar Cells
Maximum Power Voltage: 19.5V
Open Circuit Voltage: 23.4V
Maximum Power Current: 5.13A
Short Circuit Current: 5.64A
Maximum System Voltage: DC1000V
Junction Box: IP68 rated
Dimension: 1010*460*30mm
Weight: 4.9kg
Output Tolerance: ±3%
Frame: Anodized aluminium alloy
Output Cables: 4mm² (90cm)
Connector: MC4 Compatible

30A MPPT Solar Charge Controller
Battery Voltage: 12V/24V
Charge Efficiency (Peak): 99%
Self-Consumption: <10mA
USB Output: 5V / 2A (Dual USB Ports)
Overcharge Protection: 14.4V / 28.8V
Overcharge and Float: 13.7V / 27.4V
Charging Recovery Voltage: 12.6V / 25.2V
Over Discharge Protection: 10.7V / 21.4V
Over Discharge Recovery: 12.6V / 25.2V
Rated Load Current: 30A
Protection Properties: Black Current Protection, Discharge Protection
Working Temperature: -35°C to 60°C

(Price is only for pickup at Riverwood 2210 NSW. If you require shipping please contact us before your purchase)
