200W Monocrystalline Solar Panel + [Free:Solar Lights]

9BB Cell Half-Cut Technology, grade A solar cells, 24% conversion.
Anti-corrosion aluminum frame, strong and durable, longer life.
Reserved mounting holes, easy installation.
Durable in any weather

Specification
1. Module Performance
Max Power: 200W
Cell Type: Monocrystalline
Maximum Power Voltage: 18.2V
Open Circuit Voltage: 22.1V
Maximum Power Current: 10.9A
Short Circuit Current: 12.1A

2. Mechanical Specifications
Dimension: 1410 x 700 x 30 mm
Weight: 9.9 Kg
Connector: MC4 Compatible
Output Cables: 4 mm² (90cm)
Frame: Anodized aluminium alloy
Withstanding Hail: 5400 Pa
Wind Resistance: 2400 Pa
Junction Box: IP65 rated
Protection Class: IP68

3. Operating Parameters
NOCT: 41 - 45 °C
Temperature Coefficient of Voc: -0.25% / °C
Temperature Coefficient of Isc: 0.04% / °C
Temperature Coefficient of Pm: -0.34% / °C
Temperature Range [°C]: -40 - +85 °C

(Price is only for pickup at Riverwood 2210 NSW. If you require shipping please contact us before your purchase)
