Your top-tier upgrade from lead-acid to a 200Ah lithium solution is finally here-designed for superior performance and long-lasting reliability!



  • 10-year life and 4000-150000 cycles, equivalent to 3 lead-acid batteries.
  • Fast charging, 80% charge in one hour.
  • Built-in Smart BMS protection.
  • Lightweight, easy to carry.
  • No risk of leakage, safer to use, easy to expand capacity up to 4 sets.



Specification

1. Electrical Specifications

  • Battery Type: Lithium Iron Phosphate
  • Nominal Voltage: 12.8V
  • Voltage Range: 10-14.8V
  • Rated Capacity: 200Ah
  • Energy: 2560WH
  • Cycle Life: 4000-15000 Cycles
  • Connection Method: Series (Up to 4); Parallel (Up to 4); Series & Parallel (4S4P)



2. Charging Parameters

  • Charge Voltage: 14.4±0.2V
  • Maximum Charge Current: 100A



3. Discharging Parameters

  • Maximum Continuous Discharging Current: 200A
  • Discharge Cut-off Voltage: 11V



4. Mechanical Specifications

  • Dimensions: 52.5*24.5*24.5cm
  • Weight: 48.94lb
  • Protection Rating: IP65



5. Operating Parameters

  • Charge Temperature Range: 0°C~45°C (32°F~113°F)
  • Discharge Temperature Range: -20°C~65°C(-4°F~149°F)
  • Storage Temperature Range: -25C~65°C(-13°F~149°F)
  • Operation Relative Humidity: 10%~95%



(Price is only for pickup at Riverwood 2210 NSW. If you require shipping please contact us before your purchase)

12.8V 2560Wh/200Ah LiFePO4 Battery with Bluetooth Module

$899.00 Regular Price
$699.00Sale Price
Quantity
    1. Do not reverse the connection of positive and negative electrodes of the battery
    2. Do not knock, throw, or step on the battery
    3. Do not use metal to directly connect the positive and negative terminals of the battery
    4. Do not directly solder the battery or pierce it with nails or other sharp objects
    5. Do not immerse the battery in seawater or water
    6. Do not use as car starter batteries, jump starter batteries, or engine starter batteries
    7. Do not expose the battery to high temperatures as this may cause overheating, fire, malfunction, shortcircuit or shortened lifespan
